McKinley®
Sundance Spas
The spacious McKinley® spa offers room for up to seven adults. Delivering total relaxation and value, its classic hydrotherapy experience makes you feel good long after leaving the water.
Specs
Additional Specs
Jet Systems
More Details
Features
Dimensions
89" x 89" x 36"
Volume
400 gal / 1514 l
Dry Weight
778 lb / 357 kg
Seating Capacity
7
Jets
42
Primary Pump
North America (60 Hz): 2-Speed/2.5 HP Continuous, 11.0A Max., 56 Frame Export (50 Hz): 2-Speed/2.0 HP continuous, 8.0A max.
Secondary Pump
North America (60 Hz): 1-Speed/2.5 HP Continuous, 10.0A Max., 56 Frame Export (50 Hz): 1-Speed/2.0 HP continuous, 8.0A max.
Circulation Pump (Y/N)
No
Diverter Valves #
1
Filters
1
Seat Jets
Open
Water Management System
Factory installed ClearRay Active Oxygen® System
Shape
Square
Filter Type
75 ft² MicroClean® Mini™ Filter Cartridge System
Electrical
240 VAC, 60 Hz@40A, 50A or 60A Export (50 Hz): 230-240 VAC@1x16A, 1x32A or 2 out of 3-phase (see manual); or Suitably Rated Circuit Breaker to Comply with Local Electrical Regulations. Certain Countries May Require 2 Power Inputs; Two GFCI/RCD Breakers are Required for This Configuration.
Volume (Gals)
400
Filteration System
MicroClean® Mini™ Filter Cartridge System
Capacity Average (gals)
525
Capacity Volume (gals)
525
###additionalSpecs###
###jetsystems###
Throughout this 680™ Series spa, configurations and jet formations soothe muscles and release knots to renew your body. A cool down seat makes it easy to soak and socialize without completely leaving the water’s comforting warmth. And, thanks to classic jets nestled into a foot dome, your feet can find relief from almost any seat in the spa.
Clean Water
CLEARRAY Active Oxygen™ technology and an advanced MicroClean® Ultra filtration system with horizontal filter set the standard for robust, efficient water filtration. Includes CLEARRAY® On-Demand.
Lighting and Waterfalls
Stainless Steel Exterior lights plus Multicolor SunRay™ LED lighting is integrated into the spa interior and behind the AquaSheer™ waterfall.
Controls
Efficient control panel with illumination simplifies spa functions day or night.
Cabinetry Access
UV-resistant synthetic cabinetry with tool-free EZ Access Door makes maintenance a breeze.
